1703 DD L/R Rear Combination Lamps

Obserwuj produkt:
Add feedback:

Code: 13136
Manufacturer: WAŚ
1703 DD L

1703 DD P

Quantity:pcs.
Net Price: €75.12 €92.40

Fast Blik payments.

1703 DD L/R Rear Combination Lamps

Power consumption	12V	24V
Position light	max. 5.5W
Stop light	max. 6W
Direction indicator light	max. 21W
Reversing light	max 8W
Fog light	max. 5W
License plate light	0.8W	1.7W

Catalog number: 1703 DD L/R

Type: W247

Cable: 195cm

Light source: LED

Mounting side: Right/ Left

Operating voltage: 12V-24V

Stop: Yes

Position/ Rear outline: Yes

Reversing: Yes

Reflector: Yes

Fog: Yes

Rear direction indicator: Yes

Bottom license plate light: No

Dynamic indicator: Yes

functions	license plate illumination	stop light	mounting side	W247DD
				cable	Schlemmer	TYCO	WAS5	WAS7
5 T/S/I/F/R	none		left	1703 DD L	1703 DD L SCHL	1703 DD L TYCO	x	1703 DD L WAS7
			right	1703 DD P	1703 DD P SCHL	1703 DD P TYCO	x	1703 DD P WAS7

The new W247 series of LED rear combination lamps features an innovative design and a distinctive look. The new shape of the position light makes the lamps recognizable and highly visible on the road. The LED position light modules are made of a special material that hides individual light points, showing only the shape with a pleasing, neon-like light glow.

The lamps are available in 3-, 4-, and 5-light versions. The main characteristic of these lamps is the red, 3D outer lens. A unique innovation is the production of white reversing light through a red lens. The entire surface of the lens is red, so we have seamlessly achieved a position light, fog light, and stop light, while the technology allowing for a yellow direction indicator light through a red lens was developed and used in our previous lamps; therefore, the biggest innovation was achieving this white light. The combination of a red position light and a yellow direction indicator in one area creates an incredible effect. W247 series lamps are available in versions with or without bottom license plate illumination.

In the new W247 - W252 rear combination lamp series, it is possible to order lamps with a custom motif under the reflector
- ask your sales representative for details.
